13300 Battery Holder (Fork) - 3D CAD Model

FlowCad is the fast, free, and precise web app for 3D design and printing. Build professional parametric models with ease-no programming required, but it's there if you need it.

Open in FlowCad

3D Model Components

Hauptszene group
- battery casing group — Position: [0.0, -2.2, 0.0]
  - Combined Group group — Position: [0.0, 0.0, -10.5]
    - Cylinder cylinder — Position: [25.0, 9.0, 37.0], Radius: 5, Height: 10
    - Box box (Hole) — Position: [25.0, 9.0, 38.0], Size: 10 × 10 × 10
  - Combined Group group
    - Box box (Hole) — Position: [25.0, 2.0, -8.0], Size: 10 × 10 × 10
    - Combined Group group
      - Cylinder cylinder (Hole) — Position: [25.0, 10.0, 11.0], Radius: 5, Height: 10
      - Combined Group group — Position: [0.0, 1.4, 0.0]
        Box box — Position: [25.0, 7.0, 9.0], Size: 10 × 10 × 10
        Box box (Hole) — Position: [25.0, 9.0, 8.0], Size: 10 × 10 × 10
- battery template cylinder (Hole) — Position: [25.0, 8.0, 11.0], Radius: 5, Height: 10
- spring group
  - Cylinder cylinder — Position: [25.0, 8.1, -3.4], Radius: 5, Height: 10
  - Vector Shape vector_shape — Position: [18.0, 0.0, -4.0]
  - Cone cone (Hole) — Position: [24.7, -4.5, -10.3], Radius: 5, Height: 10
